Specification Sheet
gogreenledinternational.com
DLC PremiumETL Listed5-Year Warranty0-10V DimmingCCT Selectable
Linear Lighting
LED Linear Strip Light
GGL-ST
Versatile LED linear strip light with sensor base, seamless electronic linkable design, and non-yellow PC lens. 4FT and 8FT options.
20–90W
Wattage
140 LPW
Efficacy
3 Selectable
CCT
> 80
CRI
Key Features
Construction
Sensor base is available. Easy to open the strip light for quick installation. Non-Yellow PC Lens. Seamless Electronic Linkable available. 4FT and 8FT Options.
Electrical
Input Voltage: 120-277Vac. 0-10V dimmable in standard configuration. 3 Wattage and 3 CCT selectable. High lumen efficient 140lm/W on average. Sensor controls, emergency versions for options.
Applications
Offices, retail, schools, storage facilities, restaurants, healthcare, residential, and hospitality applications.
Installation
Embedded and Suspending mounting.
Listing
ETL listed, DLC Premium.
Warranty
5-year limited warranty.
Performance Data
Configurations
| Model | Size | Wattage | Lumens |
|---|---|---|---|
| GGL-GGL-WL01-45MDNC | 4FT | 20W / 30W / 45W | Up to 6,300 lm |
| GGL-ST02-8FT-90PDNC | 8FT | 70W / 80W / 90W | Up to 12,600 lm |
Specifications
Technical Details
CCT
3500K / 4000K / 5000K (3CCT Selectable)
Efficacy
140 lm/W
CRI
> 80
Input Voltage
120-277V
Operating Temp
-20°C to 45°C
Certifications
DLC 5.1 Premium (4FT) / DLC Standard (8FT), ETL
Dimming
0-10V
Linkable
With Linkable wire max 8pcs (4FT)
Warranty
5 Years
Dimensions
Physical Dimensions
Dimension Drawing
Dimensions Table
| Size / Model | Length (L) | Width (W) | Height (H) |
|---|---|---|---|
| 4FT | 47.2" | 3.3" | 2.6" |
| 8FT | 95.3" | 3.3" | 2.6" |
Installation
Installation Instructions
1
Mount the fixture to the ceiling using the provided mounting clips or directly to a junction box.
2
Connect wiring: black to black, white to white, green to ground.
3
For linkable installations, connect fixtures end-to-end using the linkable connector.
4
Install microwave sensor (if applicable) into the sensor port.
5
Attach the junction box cover plate if using a junction box.
6
Restore power and verify operation.
Mounting Options
Surface Mount
Direct surface mount to ceiling. Mounting clips included.
Linkable
Connect fixtures end-to-end for continuous row installations (max 8pcs).
Suspension Mount
Cable suspension for pendant-style installation using optional suspension kit.
