Specification Sheet
gogreenledinternational.com
UL ListedDLC Premium5-Year Warranty0-10V Dimming
Garage / Utility
LED Deformable Lamp (4-Panel Flower)
GGL-DFL-80W
High-brightness 80W 4-panel flower-style deformable LED garage lamp. 360° omnidirectional lighting with bottom light to eliminate dark areas. Aluminum housing for better heat dissipation.
80W
Wattage
140 LPW
Efficacy
2700–6500K
CCT
> 80
CRI
Key Features
Construction
Pure aluminum housing (PC+AL). 4-panel flower deformable design. 360° omnidirectional lighting. Bottom light eliminates dark areas. Better heat dissipation with aluminum material. Housing color: Black + White. Cover: Clear/Frosted.
Electrical
Input Voltage: AC100-277V 50/60Hz. 0-10V Dimmable. Surge voltage: 4000V. LED source: 268pcs Epistar SMD 2835 0.5W. Lumen output: >10,800 LM.
Applications
Warehouse, Garage, Workshop and similar applications.
Installation
E26/E27 or E39/E40 screw-in base. Direct replacement for existing lamp holders. Bypass ballast/ignitor and connect directly to AC 100-277V.
Listing
UL (E478324), DLC, CE, RoHS, FCC, PSE.
Warranty
5 years warranty.
Performance Data
Configurations
| Model | Size | Wattage | Lumens |
|---|---|---|---|
| GGL-DFL-80WX8F-CC | 80W | 80W | > 10,800 lm (140 lm/W) |
Specifications
Technical Details
CCT
2700K–6500K
Efficacy
140 lm/W
CRI
> 80
Input Voltage
AC100-277V 50/60Hz
Operating Temp
-40°C to 55°C
IP Rating
IP64
Certifications
UL, DLC, CE, RoHS, FCC, PSE
Dimming
0-10V
Power Factor
> 0.9
Base
E26/E27 or E39/E40
Surge Protection
4000V
Warranty
5 Years
Ordering Information
| Model | Description |
|---|---|
| GGL-DFL-80WX8F-CC | DFL 4-Panel Flower Deformable Lamp, 80W, E26/E27 or E39/E40 base, 140lm/W, 2700K-6500K, 0-10V Dimmable |
Dimensions
Physical Dimensions
Dimension Drawing
Dimensions Table
| Size / Model | Length (L) | Width (W) | Height (H) |
|---|---|---|---|
| 80W | Ø9.65" (245mm) | Ø9.65" (245mm) | 4.80" (122mm) |
Installation
Installation Instructions
1
Switch off power to the luminaire.
2
Remove old ballast or disconnect from existing lamp holder. Dispose of ballast per local environmental laws.
3
Remove existing lamps.
4
Bypass the ballast/ignitor and connect the lamp-holder wires directly to AC 100-277V, 50/60Hz. Ensure proper grounding.
5
Screw in new bulb into the lamp-holder firmly.
6
Switch on power.
Mounting Options
Screw-In Base (E26/E27)
Direct screw-in replacement for standard medium base lamp holders.
Mogul Base (E39/E40)
Screw-in replacement for mogul base lamp holders in high-bay applications.
Logistics
Packing Information
| Model | Carton Size | Qty / Carton | Gross Weight | Pallet Qty |
|---|---|---|---|---|
| GGL-DFL-80WX8F-CC | 18.7" × 17.7" × 20.7" (475 × 450 × 525mm) | 16 pcs | 37.5 lbs (17 kg) | — |
