Specification Sheet
gogreenledinternational.com
DLC PremiumETL Listed5-Year Warranty0-10V DimmingCCT Selectable
Linear Lighting
Up/Down Linear Light (Black)
GGL-LS03
Modern up/down linear LED light in black finish. Featuring tunable white color temperature, adjustable wattage, and multiple type combination connections.
50W
Wattage
130 LPW
Efficacy
3 Selectable
CCT
> 80
CRI
Key Features
Construction
Aluminum heatsink for efficient heat dissipation. Diffusers are extruded from impact modified acrylic for increased durability. Multiple type combination connection. Body: Black finish.
Electrical
Tunable White Color Temperature: 3000K, 4000K and 5000K. Adjustable Wattage. 0-10V Dimmable. High efficiency: 130lm/W.
Applications
Offices, conference rooms, lobbies, retail, hospitality.
Installation
Suspension installation, surface mount installation, wall mounted installation.
Listing
DLC Premium, ETL.
Warranty
5-year limited warranty.
Performance Data
Configurations
| Model | Size | Wattage | Lumens |
|---|---|---|---|
| GGL-4FT-UD-50W-30K/40K/50K-(BK) | 4FT | 50W | 6,500 lm |
Specifications
Technical Details
CCT
3000K / 4000K / 5000K
Efficacy
130 lm/W
CRI
> 80
Input Voltage
120-277 VAC
Operating Temp
-25°C to +45°C (-13°F to +113°F)
Certifications
DLC Premium, ETL
Dimming
0-10V
IP Rating
IP20 (For Indoor Use Only)
Power Factor
> 0.9
Beam Angle
100°
Lifetime
50,000+ hours
Warranty
5 Years
Ordering Information
| Model | Description |
|---|---|
| GGL-4FT-UD-50W-30K/40K/50K-(BK) | 4FT, LED Linear Suspended Up & Down Light, 50W, 3000K/4000K/5000K, Black |
Dimensions
Physical Dimensions
Dimension Drawing
Dimensions Table
| Size / Model | Length (L) | Width (W) | Height (H) |
|---|---|---|---|
| 4FT Linear | 47.64" (1210mm) | 3.15" (80mm) | 2.76" (70mm) |
| L Shape | 3.94" (100mm) | 3.94" (100mm) | — |
| T Shape | 3.94" (100mm) | 3.94" (100mm) | — |
| Cross Shape | 5.12" (130mm) | 5.12" (130mm) | — |
Installation
Installation Instructions
1
Install ceiling anchors at the desired mounting points.
2
Attach suspension cables to the fixture mounting brackets.
3
Hang the fixture and adjust cable length for desired height.
4
Connect wiring: black to black, white to white, green to ground.
5
For linked installations, connect fixtures using L, T, or X connectors.
6
Restore power and test both up and down light output.
Mounting Options
Suspension Installation
Cable suspension from ceiling for pendant-style installation.
Surface Mount
Direct surface mount to ceiling.
Wall Mounted
Wall mount installation.
Accessories
Available Accessories
L Connector
L-02(BK)
L-02(BK) — L Shape connector for 90° corner configurations.
T Connector
T-02(BK)
T-02(BK) — T Shape connector for 3-way junctions.
X Connector
X-02(BK)
X-02(BK) — Cross Shape connector for 4-way intersections.
Logistics
Packing Information
| Model | Carton Size | Qty / Carton | Gross Weight | Pallet Qty |
|---|---|---|---|---|
| GGL-4FT-UD-50W-(BK) | 49.41" × 10.16" × 10.16" | 4 pcs | 39.57 lbs | — |
| L-02(BK) | 16.1" × 14.2" × 5.3" | 12 pcs | — | — |
| T-02(BK) | 22.2" × 10.8" × 5.3" | — | — | — |
| X-02(BK) | 18.9" × 14.2" × 5.3" | — | — | — |
